Workswell GIS-320

Workswell GIS-320

The Workswell GIS-320 gas imaging system is the perfect solution for leak detection. Its unique pairing of both thermal and digital cameras makes it a versatile instrument. The GIS-320’s infra-red camera can be used to identify the escape of specific gases, as well as their presence in the air. It can also enhance environmental safety testing. This positions the Workswell unit as an aid in environmental protection, as well as in human health and safety efforts.

Workswell GIS -320
Workswell GIS -320

A Wide Spectrum of Detectable Gases

The GIS-320 can detect a wide spectrum of gases which are invisible to the naked eye. Moreover, the GIS-320 has a high sensitivity, with a detection range of between 3.2 – 3.4 µm.
Benzene
Ethanol
Ethylbenzene
Heptane
Hexane
Isoprene
Methanol
MEK
MIBK
Octane
Pentane
1-Pentane
Toluene
Xylene
Butane
Ethane
Methane
Propane
Ethylene

Ready-to-Fly Combo



The GIS-320 thermal camera is fully compatible with the DJI M600 Pro drone, and both are available in a ready-to-fly combo.

Workswell GIS -320
Workswell GIS -320

Fully Compatible with an RC Controller



The Workswell GIS-320 is the ideal solution when paired with unmanned air vehicles (drones/UAV systems). Both can be fully operated with one standard RC controller.

Standard Communication (CAN Bus and PWM Inputs)



Remote control of the thermal camera can be accomplished by using the two available input types, CAN bus (1 port) and PWM (4 free ports and 1 for the S.BUS).

Workswell GIS -320
Workswell GIS -320

Images and Video Recording



The GIS-320 can also take non-radiometric images and video for later processing. Its data is stored on a 64 GB internal disk or flash drive.

Digital Visible Camera



The Workswell GIS-320 contains a digital camera (full spectrum). Its resolution is 1920 x 1080 pixels and it has 10x optical zoom, which aids in the inspection of specific areas.

Workswell GIS -320
Workswell GIS -320

Cooled Quantum Detector



The cooled quantum detector’s resolution is 320×240 pixels, making it a powerful addition to this thermal camera. The detector operates at the very low temperature of -200°C, which increases its temperature sensitivity to 15mK. This enables it to detect very small concentrations of gas.

Weight and Dimensions



The camera’s dimensions are 201 x 150 x 105 mm, and it weighs under 1.6kg.

Workswell GIS -320

Gallery

FROM OUR CUSTOMERS ON TWITTER

Related applications

Video

Additional information

Cooled Camera
Resolution320 x 240 pixels
Temperature rangesOptional temperature ranges (integration time) -20°C…+350°C
Temperature sensitivity0.015 °C (15 mK)
Frequency30Hz
Spectral range3.2 – 3.4 μm, Cooled InSb FPA detector, powered by FLIR
Lenses24° x 18° or 14,5° x 10.8°
FocusAutomatic Motorized focusing, minimum focus distance 0.5 m
ZoomDigital zoom 1 – 4x in infrared image
Special GAS detection modeYes
Temperature level adjustmentsYes, automatic, manual or moving span
Digital Visible Camera
Resolution1 920 x 1 080 pixels (Full HD)
Focus and zoomAutofocus, 10x optical zoom with vibration compensation
Remote control & Video output
Digital interfacesS.BUS, CAN bus (for DJI control and GPS coordinates), USB 2.0 (data transfer, video recording, FW update), MavLink
Video outputDigital HDMI 720p (1280 x 720px)
Memory and data recording
Image recordingRadiometric JPEG Radiometric TIFF Non-Radiometric Digital camera JPEG Full HD
Video recording (IR, Vis)Radiometric full-frame IR recording (raw data recording)
GPS taggingMavLink, External GPS, A2 or A3 DJI compatible via CAN bus interface
MemoryInternal disk, Direct saving to external Flash drive
Measurement functions
Measurement functionsMax temperature, Min temperature, Centre temperature
File formatSaved in radiometric (raw) format in JPEG, TIFF and video WSEQ
Following gases are detected
GasesBenzene, Ethanol, Ethylbenzene, Heptane, Hexane, Isoprene,
Methanol, MEK, MIBK, Octane, Pentane, 1-Pentene, Toluene, m-xylene,
Butane, Methane, Propane, Ethylene and Propylene
Power supply & dimensions
Input supply voltage10 – 28 VDC, consumption 18 W (starting consumption 21.5 W)
Operating temperature-15°C to +50°C
Dimensions and weight201 x 150 x 105 mm, <1.6kg

GIS-320 documents

Format Name Size Link
PDF Datasheet 0.4 MB Download
PDF Drawings 0.8 MB Download
